Sciences in Cold and Arid Regions ›› 2020, Vol. 12 ›› Issue (6): 503-516.

### Characteristics and changes of permafrost along the engineering corridor of National Highway 214 in the eastern Qinghai-Tibet Plateau

Yu Sheng1,JiChun Wu1,Wei Cao1(),JianHong Fang2,AnHua Xu2,ErXing Peng1

1. 1.State Key Laboratory of Frozen Soil Engineering, Northwest Institute of Eco-Environment and Resources, Chinese Academy of Sciences, Lanzhou, Gansu 730000, China
2.Institute of Transportation Sciences of Qinghai Province, Xining, Qinghai 810003, China
• Received:2020-07-24 Accepted:2020-09-03 Online:2020-12-31 Published:2021-01-14
• Contact: Wei Cao E-mail:caowei@lzb.ac.cn
• Supported by:
the National Natural Science Foundation of China(41971093)

Abstract:

Due to a series of linear projects built along National Highway 214, the second "Permafrost Engineering Corridor" on the Qinghai-Tibet Plateau has formed. In this paper, by overcoming the problems of data decentralization and standard inconsistency, permafrost characteristics and changes along the engineering corridor are systematically summarized based on the survey and monitoring data. The results show that: 1) Being controlled by elevation, the permafrost is distributed in flake discontinuity with mountains as the center along the line. The total length of the road section in permafrost regions is 365 km, of which the total length of the permafrost section of National Highway 214 is 216.7 km, and the total length of the permafrost section of Gong-Yu Expressway is 197.3 km. The mean annual ground temperature (MAGT) is higher than -1.5 °C, and permafrost with MAGT lower than -1.5 °C is only distributed in the sections at Bayan Har Mountain and E'la Mountain. There are obvious differences in the distribution of ground ice in the different sections along the engineering corridor. The sections with high ice content are mainly located in Zuimatan, Duogerong Plain and the top of north and south slope of Bayan Har Mountain. The permafrost thickness is controlled by the ground temperature, and permafrost thickness increases with the decrease of the ground temperature, with the change rate of about 37 m/°C. 2) Local factors (topography, landform, vegetation and lithology) affect the degradation process of permafrost, and then affect the distribution, ground temperature, thickness and ice content of permafrost. Asphalt pavement has greatly changed the heat exchange balance of the original ground, resulting in serious degradation of the permafrost. Due to the influence of roadbed direction trend, the phenomenon of shady-sunny slope is very significant in most sections along the line. The warming range of permafrost under the roadbed is gradually smaller with the increase of depth, so the thawing settlement of the shallow section with high ice-content permafrost is more significant.
