Frost susceptibility of soils―A confusing concept that can misguide geotechnical design in cold regions

DaiChao Sheng1,2()

  1. 1.School of Civil & Environmental Engineering, University of Technology Sydney, Sydney Australia
    2.National Engineering Laboratory for High-Speed Railway Construction, Central South University, Changsha, Hunan 430074, China
  • Received:2020-06-12 Accepted:2021-02-02 Online:2021-04-30 Published:2021-05-11
  • Contact: DaiChao Sheng


Frost susceptibility is a concept widely used in cold region geotechnical design, to quantify the capacity of a soil in generating frost heave and frost damage. The laboratory test used to verify frost susceptibility of a soil is based on the measurement of frost heave generated in the soil under specific conditions. In reality this concept is, however, more related to the soil's potential to thaw weakening than to frost heave. Recent experimental studies show that frost non-susceptible soils like clean sand and clean gavel can also generate much ice segregation and frost heave if the conditions are favourable, hence challenging the usefulness and suitability of soil classification based on frost susceptibility. It is further shown that the concept is not suitable for design scenarios where frost heave itself is a serious hazard, such as in high-speed rail embankments.

Key words: frost susceptibility, frost heave, thaw weakening, high-speed rail

Bai R, Lai Y, Zhang M, et al., 2018. Water-vapor-heat behavior in a freezing unsaturated coarse-grained soil with a closed top. Cold Regions Sciences and Technology, 155: 120-126. DOI: 10.1016/j.coldregions.2018.08.007.
doi: 10.1016/j.coldregions.2018.08.007
Beskow G, 1935. Soil freezing and frost heaving with special application to roads and railroads. Swedish Geology Survey Yearbook, 26(3): 375. (in Swedish)
Carter M, Bentley SP, 2016. Frost Susceptibility, in Soil Properties and Their Correlations. Chichester, UK: John Wiley & Sons, Ltd. DOI: 10.1002/9781119130888.ch9.
doi: 10.1002/9781119130888.ch9
Chamberlain EJ, 1981. Frost Susceptibility of Soil, Review of Index Tests (No. CRREL-81-2), Regions Research and Engineering Lab Hanover NH.
Konrad JM, 1999. Frost susceptibility related to soil index properties. Canadian Geotechnical Journal, 36(3): 403-417. DOI: 10.1139/t99-008.
doi: 10.1139/t99-008
Liu H, Niu FJ, Niu YH, et al., 2011. Study of design of filling material and setting anti-frost layer for high-speed railway roadbed in seasonally frozen regions. Chinese Journal of Rock Mechanics and Engineering, 30(12): 2549-2557. DOI: 10.1016/j.cnsns.2011.01.018.
doi: 10.1016/j.cnsns.2011.01.018
Miller RD, 1972. Freezing and heaving of saturated and unsaturated soils. Highway Research Record, 393: 1-11. DOI: 10.1021/ba-1972-0110.ap001.
doi: 10.1021/ba-1972-0110.ap001
Miller RD, 1977. Lens Initiation in Secondary Heaving. Proc. Int. Symp. on Frost Action in Soils. Luleå University of Technology, Sweden, Vol.2. pp. 68-74.
Sheng DC, 1994. Thermodynamics of freezing soils, theory and application, Doctoral Thesis, 1994: 141D, Luleå University of Technology, Sweden.
Sheng DC, Axelsson K, Knutsson S, 1995a. Frost heave due to ice lens formation in freezing soils: 1. Theory and verification. Nordic Hydrology, 26(2): 125-146. DOI: 10.1007/BF00613312.
doi: 10.1007/BF00613312
Sheng DC, Axelsson K, Knutsson S, 1995b. Frost heave due to ice lens formation in freezing soils: 2. Field application. Nordic Hydrology, 26(2): 147-168. DOI: 10.2166/nh. 1995.0009.
doi: 10.2166/nh. 1995.0009
Sheng DC, Zhang S, Niu FJ, et al., 2014. A potential new frost heave mechanism in high-speed railway embankments. Géotechnique, 64(2): 144-154. DOI: 10.1680/geot.13.P.042.
doi: 10.1680/geot.13.P.042
Sheng DC, Zhang S, Yu Z, et al., 2013. Assessing frost susceptibility of soils using PCHeave. Cold Regions Science and Technology, 95: 27-38. DOI: 10.1016/j.coldregions.2013. 08.003.
doi: 10.1016/j.coldregions.2013. 08.003
Teng J, Shan F, He Z, et al., 2019. Experimental study on ice accumulation in unsaturated clean sand. Géotechnique, 69(3): 251-259. DOI: 10.1680/jgeot.17.P.208].
doi: 10.1680/jgeot.17.P.208
Teng J, Liu J, Zhang S, et al., 2020. Modelling frost heave in unsaturated coarse-grained soils. Acta Geotechnica, Published online at:. DOI: 10.1007/s11440-020-00956-2.
doi: 10.1007/s11440-020-00956-2
Ye YS, Wang ZJ, Cheng AJ, et al., 2007. Frost heave classification of railway subgrade filling material and the design of anti-frost layer. China Railway Science, 28(1): 1-7. (in Chinese)
Zhang S, Teng J, He Z, et al., 2016a. Canopy effect caused by vapour transfer in covered freezing soils. Géotechnique, 66(11): 927-940. DOI: 10.1680/jgeot.16.P.016.
doi: 10.1680/jgeot.16.P.016
Zhang S, Sheng D, Zhao G, et al., 2016b. Analysis of frost heave mechanisms in a high-speed railway embankment. Canadian Geotechnical Journal, 53(3): 520-529. DOI: 10.1139/cgj-2014-0456.
doi: 10.1139/cgj-2014-0456
Zhang YZ, Ma W, Wang TL, et al., 2019. Characteristics of the liquid and vapor migration of coarse-grained soil in an open-system under constant-temperature freezing. Cold Regions Sciences and Technology, 165: 102793. DOI: 10.1016/j.coldregions.2019.102793.
doi: 10.1016/j.coldregions.2019.102793
